CFG-DY16 1-Ton Kubota D722 Diesel Mini Excavator

Shop the compact CFG-DY16 mini excavator with a 10.2 kW Kubota D722 diesel engine, 67.8-inch digging depth, rubber tracks, and hydraulic dozer blade.

In stock · Ready to ship

30-day guarantee
Same-day quote
Freight nationwide
Support by phone

Call 917-695-2768 Request a Quote

SKU / ModelCFG-DY16-1-TON-KUBOTA-D7

AvailabilityAvailable now

Questions[email protected]

🛡️

30-Day Guarantee

Refund or Exchange

🚜

Kubota D722 Diesel

10.2 kW Professional Power

🚚

Free Freight Shipping

Available in Eligible Areas

Reliable Digging Power in a Compact 930 mm-Wide Platform

The CFG-DY16 is a compact one-ton-class mini excavator powered by a dependable Kubota D722-E4B diesel engine. Its narrow 930 mm body, rubber-track undercarriage, hydraulic dozer blade, and 360° working platform make it a practical solution for residential landscaping, utility trenches, drainage, farm maintenance, foundation preparation, and confined construction projects.

Key Highlights & Capabilities

Kubota D722 Diesel Engine: Delivers 10.2 kW at 2,500 rpm with up to 42.9 N·m of torque.
Compact 930 mm Width: Maneuvers through narrow gates, residential yards, gardens, and restricted access routes.
1,721 mm Digging Depth: Offers practical reach for drainage, utility lines, landscaping, and foundation preparation.
Rubber-Track Undercarriage: Provides dependable traction while helping reduce disturbance to finished surfaces.
Hydraulic Dozer Blade: Supports grading, leveling, backfilling, and machine stabilization.
Gear-Pump Hydraulic System: Delivers 17.6 L/min flow at a working pressure of 16 MPa.
Grease-Cylinder Track Tensioning: Supports convenient undercarriage adjustment and routine maintenance.

Technical Specifications

Specification	Details
Model	CFG-DY16
Machine Type	Crawler Backhoe Mini Excavator
Operating Weight	1,050 kg / approximately 2,315 lb
Bucket Capacity	0.022 m³
Engine	Kubota D722-E4B-2FM-1 diesel
Rated Output	10.2 kW at 2,500 rpm
Maximum Torque	42.9 N·m at 2,000 rpm
Maximum Travel Speed	2 km/h
Slewing Speed	8 rpm
Gradeability	30°
Transport Dimensions	2,873 × 930 × 2,257 mm (113 × 36.6 × 88.9 in)
Height Without Canopy	2,025 mm / 79.7 in
Rubber Track Width	180 mm / 7.1 in
Track Center Distance	746 mm / 29.4 in
Track Length	1,200 mm / 47.2 in
Ground Pressure	0.3 kgf/cm²
Maximum Digging Height	2,483 mm / 97.8 in
Maximum Dumping Height	1,738 mm / 68.4 in
Maximum Digging Depth	1,721 mm / 67.8 in
Vertical-Arm Digging Depth	1,645 mm / 64.8 in
Maximum Digging Radius	3,034 mm / 119.4 in
Ground-Level Digging Reach	2,938 mm / 115.7 in
Front Turning Radius	1,941 mm / 76.4 in
Dozer Blade Size	937 × 210 mm (36.9 × 8.3 in)
Blade Lifting Height	170 mm / 6.7 in
Blade Digging Depth	240 mm / 9.4 in
Hydraulic Pump	Gear pump
Hydraulic Pressure and Flow	16 MPa / 17.6 L/min
Hydraulic Tank Capacity	15 L
Fuel Tank Capacity	16 L
Engine Oil Capacity	3.5 L

Configuration notice: Confirm the included bucket, canopy, attachment connections, and final equipment configuration with customer service before ordering.
